EOD Gear, CWMD Supplies, and CBRN Protection Equipment

The SETS™ Responder system allows first responders to use existing medical cylinders for exothermic cutting during rescue operations. The system gives the first responder the ability to burn through metal, locks, and hinges with ease.

The SETS™ Responder was designed for use in conjunction with medical oxygen cylinders with a CGA870 post valve connection.

SPECIFICATIONS

• Can be used with existing medical oxygen cylinders (post style)

• CGA870 regulator connection

• Quick connect/disconnect rod cutting control handle

• 9V battery rod ignition

• Compact nylon carry case

• Dimensions (with medical "D" cylinder): 22" L x 9.5" W x 5.5" H

• Weight (with medical "D" cylinder): 13.5 lbs.

• Cutting capability: (3) 18" SETS Exothermic Rods @ 2000 psi (O2)



The Pelican® Mounted Pump System (PMBPS™) was designed for mobility and ease of use for the transport of oxygen boosting capabilities for the refilling of oxygen systems.

The PMBPS™ is built within a mobile hard case with boosting capability of 3,000 PSI. The case includes everything needed for oxygen regulation for a safe rate of filling.

The PMBPS™ is available with optional charge hose connections for use with a variety of oxygen systems.

PMBPS™ SYSTEM FEATURES

• Voltage Requirements: 120 60 Hz VAC Driven (also available in 220V 50 Hz)
• Integrated HP regulator for maintaining safe oxygen charge rate
• Compact control panel for operation of the system
• Dimensions: 26.5" L x 25.25" D x 26.5" W

• Weight: 166 lbs (75.3 Kg)

The Twin Vessel Air Storage System (TVASS) is a large volume mobile compressed air workstation. Developed to provide a modular and mobile platform for a refill of SCBA for systems for operations that require larger volumes of air. The TVASS provides up to 902 CF (@ 6000 psi) of compressed breathable air, giving a team requiring a very large, but portable reservoir of breathable air a sizeable advantage in almost any situation. The TVASS was designed to be stacked and connected together to create a larger bank of air depending on operational needs. The modularity provides the end-user the ability to use on any vehicle platform in inventory.

SPECIFICATIONS

• Twin 1910 cu in aluminum lined carbon fiber cylinder
• Cylinders can be used independently or together without user connection
• Each cylinder has a 3 ft. dual FD17 (Female/Male) charge block hose with a pressure gauge for an independent refill or cascade with separate connected TVASS
• QF4 Manifold Connected with isolation on/off valve with bleed for connection to separate TVASS, bank, or AirJam system. This allows for large volumes of air to be transfered without freezing over time
• Removable and stowable wheels for system stacking and mobility when needed.
• Built-in mounting system for connecting multiple TVASS systems together
• Dimensions: 56.5" H x 12" D x 23" W
• Weight: 196 lbs empty/252 lbs filled @6000 psi
• Capacity: 25,542.9 L @ 6000 psi (902 cubic ft)

Exothermic Cable is a consumable electrode, flexible spiral cable encased within a protective sheath. Exothermic Cable has a threaded male fitting that attaches to the charging handle and the other end for cutting. Exothermic Cable is manufactured in three diameters: 6mm, 9mm & 12mm.

• Can cut variable metal thickness
• The flexibility of cable allows for cutting in hard to reach areas
• No electrical hazard after ignition
• Ability to cut subsurface and surface

Avon's state-of-the-art ST54™ Tactical Operator SCBA has been developed specifically for the tactical officer and technician applications where the operator needs to respond to ever changing operational conditions. The ST54™ SCBA is the base to a multi-mission Respiratory Protection System which provides for operational flexibility to the operator and mission commanders in the field to tailor the PPE response based on the available intelligence. Depending on the threat or operational situation at the scene of an incident, the ST54 SCBA can be configured to provide the appropriate protection. The ST54™ SCBA combines Avon Protection Systems' M53A1, FM53 and FM54 respirators (see respirator datasheets for further details) with new and innovative modular breathing apparatus technology to provide positive pressure SCBA and/or PAPR capability. The ST54™ system provides the operator with total flexibility to select the necessary level of protection quickly and efficiently without degradation of operational effectiveness. Designed with the tactical mission in mind, the system incorporates non-reflective black components and warning whistle, which can be silenced.

The Avon C50 was developed from the US Military Joint Service General Purpose Mask (JSGPM/M50) and is now recognized as the mask of choice for Law Enforcement officers. C50 provides greater operational flexibility, improved communications and longer lasting comfort while countering multiple threat scenarios CBRN agents, toxic industrial chemicals and toxic industrial materials. The C50 is NIOSH CBRN APR Standard Cap1 approved when outfitted with an approved CBRN filter. The Responder Kit has been specifically developed with the help of industry experts to provide a total CBRN respiratory solution for the end user. The kit provides a reduced acquisition cost when compared to purchasing the included items separately.

Kit Includes: C50 CBRN Twin Port Mask, Clear and Sunlight Outsert Assemblies, CBRN filter, Riot Agent filter, Mask Carrier and Faceform.

Based on the US Government Joint Service General Purpose (JSGPM) program, the M53A1 is designed to meet the unique requirements of Special Mission Units while providing the maximum operational flexibility. The M53A1 was developed to counter the military unique and domestic threats encountered on the modern battlefield, global war on terrorism, and CBRN operations around the world. The M53A1 provides excellent protection against traditional chemical and biological agents, select toxic industrial chemicals (TICs), and particulate matter including radioactive dust. The M53A1 is first dual US DOD protective mask; certified to MIL-SPEC PR EA-M-10034 and NIOSH CBRN APR. The M53A1 can function as a conventional negative pressure or air purifying respirator (APR), powered-air purifying respirator (PAPR), Self-Contained Breathing Apparatus (SCBA), closed-circuit breathing apparatus (CCBA) and combination SCBA and PAPR systems.

ROSIE provides a quick, safe and effective skin temperature of an individual with a + 0.3°F (+.15°C) accuracy rate without being in close contact. ROSIE supplies an automated non-contact temperature scan at a range of 6 –10 feet (1.8 – 3.0 meters) and has a quick and easy set-up allowing for mobility of the system. ROSIE alerts the operator of individuals with elevated temperatures and has the ability to scan and return results in approximately one second.

Key Features and Benefits:

• Thermal Imaging measures skin temperature faster with the same accuracy as forehead thermometers
• Increases the rate of screening of individuals entering a facility• Setup and configuration in less than an hour by one person
• Can be permanently mounted or operated on a tripod
• PII or health information is not stored or displayed by the system

Compliant with Food and Drug Administration (FDA) COVID 19 Telethermographic Systems guidelines:

This system incorporates elements of the software developed by the MITRE corporation on behalf of the U.S. Government. MITRE is a registered trademark of the MITRE Corporation

Shadow System - Super Light Tactical System

• 12SF Detector – weighs only 2.2 lbs. (1kg) and images just 0.12" (3mm) from bottom & side! Providing outstanding image quality and 90mm (3.5") steel penetration with Golden XRS-3, 100cm (39.4") drop test, and 200kg (440 lbs.) load proof
• Android Phone / Windows Tablet operation
• Wired & Wireless operation modes
• Digital Amorphous Silicon Detector, not a CR plate that needs to be scanned
• Highest reliability - solid-state, no moving parts
• The entire system (including the XR150) weighs only 8.8 lbs. (4kg) and fits in a small day pack
• Compatible with Android XTK

Rapiscan System's ORION® 900 series of single-view and dual-view baggage and parcel transmission X-ray systems feature enhancements in overall image quality, steel penetration, wire resolution, and spatial resolution. Performance enhancements are achieved through a combination of detector technology, state-of-the-art electronics, distortion correction features, and imaging software techniques for material discrimination. Various tunnel sizes accommodate small parcels up to large pallets. Our GEMINI® series features combined transmission and backscatter X-ray technologies to easily detect metallic objects such as knives and guns and organic materials such as drugs and currency hidden in cluttered parcels.

Rapiscan | AS&E's cargo and vehicle X-ray inspection systems help customers find threats and contraband with ease and confidence, while maximizing operational efficiency. Our range of high-to-low energy cargo and vehicle screening systems comes in a variety of configurations—mobile, portal, gantry, rail, trailer, air cargo, and handheld—and many leverage a combination of X-ray technologies to simultaneously provide multiple views of the scanned object for greater assistance with detection. Our analyst assist tools highlight potential threats and contraband, allowing analysts to focus on suspect areas and enhance detection.

The SWIFT Pole Camera is a compact, quick to deploy camera that provides low light and thermal video at an extended reach over 3 feet.

Two separate image sensors are contained within the camera head: a visible 640x480 CMOS image sensor with excellent low-light sensitivity (16V/lux-sec) that is bolstered by on-board 950nm Infrared illumination, and a FLIR Long-Wave Infrared (LWIR) sensor with 160x120 resolution. Video from these two sensors provides two distinct views for the operator: a color low-light view and a white-hot thermal view.

Video is displayed in dual-view on the attached 4" LCD Monitor, located on the SWIFT Pole Camera's handle. The telescoping carbon fiber pole can be deployed in seconds, without the need to twist or lockdown sections. The SWIFT Pole fully extends over 3 feet and collapses to 13 inches when stowed. Utilizing the integrated hook at the end of the pole allows you to easily extend and collapse the pole with one hand.

The SWIFT Under Door Camera is a size, weight, and power optimized Under Door Camera that is compact enough to fit within a Double M4 Mag Pouch. Featuring up to four individual cameras located within a .26" thick insertion panel, the SWIFT Under Door Camera provides viewing in four directions inside a room: forward, upward/backward, left, and right. Each viewing direction is supplemented with covert 950nm Infrared LED illumination for both low-light & no-light environments.

The SWIFT Under Door Camera is equipped with a Tactical Accessory Port (TAP) which provides USB and Ethernet connectivity as well as an auxiliary 12VDC power input. The integrated USB and Ethernet ports and on-board 5GHz Wi-Fi allow for video to be streamed to any Tactical Electronics' Monitors, the TE View App or ATAK on Android devices, or MANET radios. All SWIFT products offer Stand By mode to help preserve battery life and provide a quick return to video within 10 seconds.

The SWIFT Video Scope features an 8mm distal tip and 4-way articulation. Video is viewable through the built-in eyepiece, on any Tactical Electronics monitor, or an Android device with the TE View mobile app. The 8mm distal tip provides illumination by an adjustable internal 400nm UV LED.

The camera head moves in four directions (160° up, 130° down, 100° left/right) and is controlled via fine-touch paddles. The SWIFT Video Scope is available with a 12in or 24in long probe. The SWIFT Video Scope features a rugged, locking Tactical Accessory Port (TAP) that provides USB 2.0, 100Mbps Ethernet, and 12VDC power in. The USB and Ethernet interfaces can be used to stream video to any Tactical Electronics Monitor, ATAK, TE View App, or MANET radios. All SWIFT products offer Stand-By Mode to help preserve battery life and provide a quick return to video within 10 seconds."

MX908 is an easy-to-use device, purpose-built for trace detection and identification of chemical threats at the point of need. It is a multi-mission, handheld mass spectrometer utilizedby elite responders conducting chemical, explosive, priority drug, and hazmat operations around the world.

Highlights include:

• Trace level (nanogram and ppb) detection and identification of chemical threats
• An only device capable of detecting and identifying aerosolized threats such as CWAs and PBA
• Only handheld device capable of identifying A-Series chemical warfare agents

The MX908® Aero enables operators to detect and identify aerosolized threats—such as Chemical Warfare Agents (CWAs) and Pharmaceutical-based Agents (PBAs) —which represent a critical gap in existing trace chemical detection solutions.

MX908 Advantages:

• The only field-deployable tool is available now for rapid trace detection and identification of aerosol threats.
• Simultaneous monitoring, detection, and identification of both vapor and aerosol threats.
• Flexible sampling modules for easy transition from trace solid and liquid sampling to vapor and aerosol sampling.
• The optional accessory can be quickly deployed to fielded units or be purchased with new MX908 devices.

The F90 ballistic helmet features the perfect combination of performance and weight at an economical price. The F90 shell is constructed of 100 % UHMWPE ballistic material and is > 15 % lighter than the ACH helmet. To create exceptional performance Avon Protection utilizes a proprietary and innovative helmet molding technology that produces one of the highest 17 gr V50 results on the market! Available in Mid-Cut, Full-Cut & High-Cut. Suitable for First Responders, Military, & Special Forces.

Sunlight outsert is for protection against high level UV light and flash flare. The outsert hides the wearers eyes to provide a psychological advantage in a threat scenario.

Mirrored outsert is for protection of UV light and improve contrast and depth perception. In addition, they hide the wearers eyes while reflecting the surroundings to provide psychological advantage in a threat situation.

BlueBlocker outsert is for specialist use to improve weapon sighting by filtering out blue light wavelengths to deliver a sharper image. This outsert is ideal for snipers.

Shade 5 Breach outsert provides eye protection for specialist operators while deploying a cutting torch.

Laser outsert is for the removal of harmful laser wavelengths commonly produced by laser sighted weapons.

This VPU (Voice Projection Unit) is specially designed for the C50 and FM50 masks. The VPU and internal microphone can easily be connected via the Electronic Communication Port (ECP) on the mask

The GEN II VPU when deployed with the FM53, FM54 or M53A1 Air Purifying Respirators; the most tactically advanced masks in the world, provides the operator with the best-in-class respiratory communications platform available today.
